Sonic CUBIC+ (BS)
Acoustic Box Shade Luminaire
Architectural sound absorbing Eco Felt Acoustic panel.
Made from recyclable plastic material available in different thicknesses.
Class1 Fire rated with 0.7 Noise Reduction Coefficient/1” Acoustic.
Light source: COB LED.
High efficiency integral reflector combined with opal lens insert provides excellent lighting distribution.
Square internal louver is available in a wide range of finishes.
Aluminum body of the luminaire comes with built-in-driver.
LED Spot is rated for 60,000hrs. L70 with +90 CRI.
Has a proven record in office, commercial and retail installations.
Custom modifications are available.
ED luminaires are certified to CSA and UL Standards.
Made from recyclable plastic material available in different thicknesses.
Class1 Fire rated with 0.7 Noise Reduction Coefficient/1” Acoustic.
Light source: COB LED.
High efficiency integral reflector combined with opal lens insert provides excellent lighting distribution.
Square internal louver is available in a wide range of finishes.
Aluminum body of the luminaire comes with built-in-driver.
LED Spot is rated for 60,000hrs. L70 with +90 CRI.
Has a proven record in office, commercial and retail installations.
Custom modifications are available.
ED luminaires are certified to CSA and UL Standards.
Resources
Materials
- Aluminum
- Felt
- Polycarbonate
Mounting
- Suspended
Color / Finish
- Black
- Grey
- White
Lumens
- 1400 Lm
- 1430 Lm
- 1460 Lm
- 1910 Lm
- 1950 Lm
- 1990 Lm
- 2350 Lm
- 2400 Lm
- 2450 Lm
Watts
- 15 w
- 20 w
- 25 w
CCT
- 3000K
- 3500K
- 4000K
CRI
- 85 CRI
Circuit
- Single Circuit
Dimensions
- H: 12 In. L: 12 In. W: 12 In.
- H: 16 In. L: 16 In. W: 16 In.
- H: 24 In. L: 24 In. W: 24 In.
Dimming Protocol
- 0-10 V
- DALI
- DMX
- ELV
- Triac
Dimming Range
- 1%
- 10%
- < 1%
Dynamic LED Color
- BIOS Dynamic
Lamp Life
- 60000 hrs
Lamp Source
- LED
Listings
- cULus
Ratings & Compliance
- Declare
- Fire Rated
- Made in Canada
Static LED Color
- BIOS Static
Voltage
- 120 V
- 277 V
Warranty
- 5 yr
